Stinson 108 Voyager

Touring Aircraft

Stinson 108-3 Voyager F-BFPM 1085080 © Karsten Palt
Photo ©: Karsten Palt
The Stinson 108 Voyager is a light single-engine four-seat touring aircraft produced by the American manufacturer Stinson Aircraft Company a division of Consolidated Vultee, later by Piper Aircraft as the Piper Voyager also called Piper Flying Station Wagon.
The Stinson 108 Voyager is a development of the pre-WWII Stinson Model 10 Voyager.
Crew1
Passengers2-3
Propulsion1 Piston Engine
Engine ModelFranklin 6A4-165-B3
Engine Power123 kW165 hp
max. Cruise Speed204 km/h110 kts
  127 mph
max. Speed (vne)274 km/h148 kts
  170 mph
Service Ceiling3.962 m13.000 ft
Rate of climb198 m/min650 ft/min
Range800 km432 NM
497 mi.
Empty Weight587 kg1.294 lbs
max. Takeoff Weight1.089 kg2.400 lbs
Wing Span10,30 m33 ft 10 in
Wing Area14,4 m155 ft
Length7,70 m25 ft 3 in
Height2,30 m7 ft 7 in
First Flight1945
Production Statusout of production
Total Production>5000
Developed fromStinson Model 10 Voyager
ICAO CodeS10 S108
FAA TCDSA-767
Data for (Version)Stinson 108-3 Voyager
VariantsStinson 108, 108-1, 108-2, 108-3

[Photo-ID: 7699] Karsten Palt 2013-10-13
Stinson 108 Voyager, , , c/n , Karsten Palt, 2013Stinson
108 Voyager

under Restoration
Aviation Museum of Kentucky [Lexington]
[Photo-ID: 7480] Karsten Palt 2013-09-07
Stinson 108-1 Voyager, , N8140K, c/n 108-1140, Karsten Palt, 2013Stinson
108-1 Voyager
Reg.: N8140K
c/n: 108-1140

Oldtimer-Fliegertreffen 2013 [Kirchheim unter Teck - Hahnweide (EDST)]
[Photo-ID: 2694] Karsten Palt 2009-09-05
Stinson 108-3 Voyager, , F-BFPM, c/n 1085080, Karsten Palt, 2009Stinson
108-3 Voyager
Reg.: F-BFPM
c/n: 1085080

Oldtimer-Fliegertreffen 2009 [Kirchheim unter Teck - Hahnweide (EDST)]
[Photo-ID: 10740] Karsten Palt 2014-10-23
Stinson C-108 Voyager, Spanish Air Force, L.2-21, c/n 108-5162, Karsten Palt, 2014Stinson
C-108 Voyager
Spanish Air Force
Reg.: L.2-21
c/n: 108-5162

ex EC-AEY
Museo del Aire [Madrid]
