Zlin (Moravan) Zlin Z 43

Trainer / Touring Aircraft

Moravan Zlin Z-43 D-EKMX 0025 © Karsten Palt
Photo ©: Karsten Palt
The Zlin Z 43 is a single-engine four-seat touring and trainer aircraft produced by the Czechoslovak resp. Czech manufacturer Moravan Otrokovice (today ZLIN Aircraft Otrokovice, Czech Republic).
The Zlin Z 43 is a development of the Zlin Z 42 with enlarged cabin, different wings and a more powerful engine. The Z 43 was license built in Algeria as the Safir-43.
Crew1
Passengers3
Propulsion1 Piston Engine
Engine ModelWalter / LOM M-337A
Engine Power154 kW207 hp
Speed235 km/h127 kts
  146 mph
Service Ceiling3.800 m12.467 ft
Range1.100 km594 NM
684 mi.
Empty Weight730 kg1.609 lbs
max. Takeoff Weight1.000 kg2.205 lbs
Wing Span9,76 m32 ft 0 in
Wing Area14,5 m²156 ft²
Length7,75 m25 ft 5 in
Height2,91 m9 ft 7 in
First Flight1968
Production Statusout of production
Total Productionca. 80
Developed fromZlin Z 42
ICAO CodeZ43
EASA TCDSA.028
Data for (Version)Moravan Zlin Z 43

next aircraft
[Photo-ID: 7500] © Karsten Palt 2013-09-07
Moravan Zlin Z-43, , D-EKMX, c/n 0025,© Karsten Palt, 2013Moravan
Zlin Z-43
Reg.: D-EKMX
c/n: 0025

ex NVA (GST) 19
Oldtimer-Fliegertreffen 2013 [Kirchheim unter Teck - Hahnweide (EDST)]
[Photo-ID: 3465] © Karsten Palt 2010-06-11
Moravan Zlin Z-43, Private (Black Jacks), D-EWFG, c/n 0043/01,© Karsten Palt, 2010Moravan
Zlin Z-43
Private (Black Jacks)
Reg.: D-EWFG
c/n: 0043/01

ILA Berlin 2010 [Berlin - Schönefeld (EDDB / SXF)]
