BAe, British Aerospace BAe 146-100 / AVRO RJ70
Regional Airliner
Photo ©: Karsten Palt
The British Aerospace BAe 146-100 / AVRO RJ70 is a four-engined regional airliner with a capacity of maximum 94 passengers produced by the British manufacturer British Aerospace (today BAE Systems). It is part of the BAe 146 / AVRO RJ family of regional airliner.
The BAe 146 was developed by Hawker Siddeley as the HS.146. The AVRO RJ70 is a modernized variant which was introduced in 1992.
| Crew | 2 | |
| Passengers | 70-94 | |
| Propulsion | 4 Turbofan Engines | |
| Engine Model | Honeywell LF507-1F | |
| Engine Power (each) | 31,1 kN | 7000 lbf |
| alternative Engine Variant | ||
| Engine Model | Lycoming / Honeywell ALF 502R-5 | |
| Engine Power (each) | 31,1 kN | 7000 lbf |
| Speed | 780 km/h | 421 kts 484 mph |
| Mmo (max. Mach) | Mach 0.73 | |
| Service Ceiling | 9.449 (10.668) m | 31.000 (35.000) ft |
| Range | 3.000 (3.074) km | 1.620 (1.660) NM 1.864 (1.910) mi. |
| Empty Weight | 23.288 (23.900) kg | 51.341 (52.690) lbs |
| max. Takeoff Weight | 38.102 (43.091) kg | 84.000 (95.000) lbs |
| max. Landing Weight | 35.153 (37.875) kg | 77.500 (83.500) lbs |
| Wing Span | 26,34 m | 86 ft 5 in |
| Wing Area | 77,3 m² | 832 ft² |
| Length | 26,16 m | 85 ft 10 in |
| Height | 8,61 m | 28 ft 3 in |
| First Flight | 03.09.1981 (23.06.1992) | |
| Production Status | out of production | |
| Production Range | 1983-2003 | |
| Total Production | 35 (12), Total 47 | |
| ICAO Code | B461 RJ70 | |
| IATA Code | 141 146 14F 14X AR7 | |
| FAA TCDS | A49EU | |
| EASA TCDS | A.182 | |
| other TCDS | CAA UK BA16 | |
| Data for (Version) | BAe 146-100A (RJ70) | |
| Variants | BAe 146-100, AVRO RJ70, BAe 146-100QC, BAe 146-100QT, BAe 146 Statesman | |
| [Photo-ID: 1542] © Karsten Palt 2008-09-28 | |
 | BAe AVRO RJ70 Transwede Airways Reg.: SE-DJP c/n: E1254 |
| [Brussel/Bruxelles - Brussels Airport (EBBR / BRU)] | |
